Pre-opened Bag Making Machine

  • Pre-open Bag On Roll Making Machine
  • Pre-open Bag On Roll Making Machine
  • Pre-open Bag On Roll Making Machine
  • Pre-open Bag On Roll Making Machine
  • Pre-open Bag On Roll Making Machine
  • Pre-open Bag On Roll Making Machine
  • Pre-open Bag On Roll Making Machine
Pre-open Bag On Roll Making MachinePre-open Bag On Roll Making MachinePre-open Bag On Roll Making MachinePre-open Bag On Roll Making MachinePre-open Bag On Roll Making MachinePre-open Bag On Roll Making MachinePre-open Bag On Roll Making Machine

Pre-open Bag On Roll Making Machine

  • OEM Support
  • China Factory
  • Best Price
  • Quickest Delivery
  • Product description: We are the leading and professional China Pre-opened Bag On Roll Making Machine,Pre-opened Bag Making Machine,Pre-opened Bag Converting Machine manufacturer.
  • INQUIRY

Performance And Characteristics:
This pre-opened bag making machine/pre-opened bag on-a-roll making machine is our newest design machine,it has much functions as photoelectric automatic tracking microcomputer length setting,highlimit stopping,automatic counting,automatic alarm on reaching the set value,high compensation accuracy with such characteristics as neat bags,little error and high automatic of whole machine,so it is a kind of ideal equipment for producing pre-open bag to match the line of autobag,titan, sharp packing machine.

Model

PRE-600

Max.width of Bag-making

550mm

Max.length of Bag-making

1000mm

Max diameter of unwinding(can be special design)

600mm

Max diameter of rewinding(can be special design)

400mm

Max.speed of Bag-making

30-150 pcs/min

Paper core of unwinding(can be special design)

3inch (76mm)

Paper core of rewinding(can be special design)

3inch (76mm)

Thickness of film(single layer)

0.008-0.15mm

Electric Power

12 kw

Overall Dimensions

5800*1200*1600mm

Weight

2000kgs

The purpose of the pre-opened bag making machine is to solve the above problems and shortcomings, to provide a single-sided pre-opened bag suitable for automatic feeding, automatic heat sealing and automatic cutting, which can be used with the machine, so as to save labor costs and improve work efficiency.The purpose of the utility model is achieved through the following technical solutions: a single-sided pre-opened bag, including several plastic bags, one side zigzag point connection between the plastic bag and the plastic bag, and the other side between the plastic bag and the plastic bag. With opening.Further, the single-sided pre-opened bag on-a-roll includes several plastic bags, one side between the plastic bags and the plastic bags is zigzag point connection, the other side is integrally connected with the upper and lower ends of the plastic bag and the plastic bag, and the middle is open. The one-piece connection length is 5mm.

Because the utility model adopts the above-mentioned packaging structure, the assembly line directly puts the articles into the plastic bag, and the machine automatically recognizes and completes the feeding action, performs heat sealing and cuts off the connection with the previous plastic bag. It can save post operators, and complete the packaging process by mechanical automation, improve work efficiency, and realize large-scale fully automated operations.

New development on SNDA Pre-opened Bag Making Machine

1.      Except the narmal pre-opened bag on-a-roll making machine,we also developed and improved several type of such bag machine with different type bag finished.

Normal  bag picture as below:


----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

2.      Pre-open Bag On Roll Making Machine with 1 Sealing 2 Perforating(one is side easy open line)


The bag is our another new design on our pre-open bag making machine,it has 1 sealing line,2 perforating line(one is side easy open line).

About the two perforating lines,one is on bag bottom and another on bag side,the bottom one is for normal pre-open inline when we do bag making,another is pre-cut perforating line for bag side easy open when we finished packing item inside the bag.

----------------------------------------------------------------------------------------------------------------------------------------------------------

3. Pre-open Bag On Roll Making Machine with 1 Sealing 2 Perforating(one is top easy open line)

The bag is our another new design on our pre-open bag making machine,it has 1 sealing line,2 perforating line(one is top easy open line).


About the two perforating lines,they are on bag top and bottom,one is for normal pre-open inline on bag bottom when we do bag making,another is pre-cut perforating line on bag top for bag easy open when we finished packing item inside the bag.Also this pre-cut perforating line for bag easy open have two design,one is full bag width perforating,another is 60%-80% or more or less open.This can be adjusted by switching the perforating blade width(Double perforating blade we can offer in different width).

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

4. Pre-open Bag On Roll Making Machine with 2 Sealing 2 Perforating(one is side easy open line)

The bag is our another new design on our pre-open bag making machine,it has 2 sealing line,2 perforating line.


About the two sealing line,why customer choose two sealing lines,because they make mexico-hat punching/euro punching/banana punching/handle punching on the bag too,then after the bag finished item packing,it can be hung easily.

About the two perforating lines,one is on bag bottom and another on bag side,the bottom one is for normal pre-open inline when we do bag making,another is pre-cut perforating line for bag side easy open when we finished packing item inside the bag.

-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

5. Pre-open Bag On Roll Making Machine with 2 Sealing 2 Perforating(one is top easy open line)

The bag is our another new design on our pre-open bag making machine,it has 2 sealing line,2 perforating line(one is top easy open line).


About the two sealing line,why customer choose two sealing lines,because they make mexico-hat punching/euro punching/banana punching/handle punching on the bag too,then after the bag finished item packing,it can be hung easily.

About the two perforating lines,they are on bag top and bottom,one is for normal pre-open inline on bag bottom when we do bag making,another is pre-cut perforating line on bag top for bag easy open when we finished packing item inside the bag.Also this pre-cut perforating line for bag easy open have two design,one is full bag width perforating,another is 60%-80% or more or less open.This can be adjusted by switching the perforating blade width(Double perforating blade we can offer in different width).
